Key Features and Details

Stock #217109
CategoryLoaders
ClassEarthmoving
Hours—

Dealer Comments

2026 JCB 427 Agri, The JCB 427 AGRI is designed to maximize efficiency and, with it, productivity. Its all-day comfortable a comfy operator is, after all, a productive one. Its also safe, serviceable and, with features like Eco Mode and Auto Idle, its highly fuel-efficient too.

Specifications

Body	Earthmoving
Category	Loaders
Make	JCB
Stock Number	217109
Veh Type	New
Vin	3582197
Year	2026
Chassis Type	Articulated
Tire Type	Radial
Tire Size Standard	20.5 R25
Tread Classification	L3

Max Lift Height	3718 mm [12ft 2in]
Wheelbase	3050 mm [10ft]
Track Gauge	1955 mm [6ft 5in]
Dump Angle	45 °
Hydraulic System	210 L [55.5 gal]
Bucket Breakout	138 kN [31024 lbf]
Load Centre	600 mm [24 in]
Pump Type	Variable Displacement Pump
Turn Radius Over Tires	5483 mm [18ft]
Reach Max Height	802 mm [2ft 8in]
Bucket Heaped Capacity	1.9 m³ [2.49 yd³]
Bucket Largest Capacity	2.7 m³ [3.53 yd³]
Bucket Smallest Capacity	1.9 m³ [2.49 yd³]
Bucket Type	GP w/Edge
Carry Crowd Angle	48 °
Crowd Height Maximum Height	58 °
Dump Angle Maximum	49 °
Fork Tines	1220 mm [48 in]
Fork Tipping Load Full Turn	9587 kg [21136 lb]
Fork Tipping Load Straight	10224 kg [22540 lb]
Full Lift Dump Height	2944 mm [9ft 8in]
Full Lift Reach	897 mm [2ft 11in]
Full Turn Tipping Load	9478 kg [20896 lb]
Ground Crowd Angle	43 °
Inside Wheel	2896 mm [9ft 6in]
Load Sensing Pressure 1	250 bar [3626 psi]
Load Sensing Pressure 2	160 bar [2321 psi]
Loader Control	Joystick
Loader Geometry	Parallel
Pivot Pin Height	3876 mm [12ft 9in]
Pump Cumulative Flow	252 L/min [66.6 gal/min]
Pump Flow 1	126 L/min [33.29 gal/min]
Pump Flow 2	126 L/min [33.29 gal/min]
Reach 2130mm 45 Dump	1644 mm [5ft 5in]
Reach Ground	769 mm [2ft 6in]
Straight Tipping Load	11038 kg [24334 lb]
Turn Radius Over Bucket Std	5902 mm [19ft 4in]

Engine Manufacturer	Cummins
Engine Model	QSB
Displacement	6.7 L [409 in³]
Fuel Tank	290 L [76.6 gal]
Cooling	Water
Emissions	DieselT4
Net Output	109 kW [146 hp]
Rated Speed	2100 rpm
Aspiration	Turbocharged
Def Tank	40 L [10.6 gal]
After Treatment System	Selective Catalytic Reduction
Net Rating Standard	ISO 9249

Transmission Type	Automatic
Articulated Steering Angle	± 40 °
Front Differential Type	Limited Slip
Front Drive Type	Epicyclic
Front Fixed Trunnion	Fixed
Number Of Ranges	4F - 3R
Oscillation Rear Axle	10.5 °
Parking Brake Actuation	Electro-Hydraulic
Parking Brake Type	Disc - Transmission
Rear Differential Type	Limited Slip
Rear Drive Type	Epicyclic
Rear Fixed Trunnion	Trunnion
Service Brake Actuation	Hydraulic
Service Brake Type	Wet Multi Disc
Torque Converter	Lock Up Option

Ground Clearance	472 mm [19 in]
Height Over Cab	3360 mm [11ft]
Bucket Width	2550 mm [8ft 4in]
Length With Bucket On Ground	7070 mm [23ft 2in]
Width Over Tires Std	2483 mm [8ft 2in]

Torque	841 Nm [620 lbf·ft]
Gross Output	118 kW [158 hp]
Torque Rated Speed	1500 rpm
Forward Max Speed	38.5 km/h [23.92 mph]
Forward Speed 1	6.6 km/h [4.08 mph]
Forward Speed 2	13.1 km/h [8.13 mph]
Forward Speed 3	23.5 km/h [14.6 mph]
Forward Speed 4	38.5 km/h [23.92 mph]
Reverse Maximum Speed	24.7 km/h [15.32 mph]
Reverse Speed 1	6.9 km/h [4.31 mph]
Reverse Speed 2	13.8 km/h [8.56 mph]
Reverse Speed 3	24.7 km/h [15.32 mph]

Steering Axle Type	Articulation

Please confirm all features with dealer.
