JCB S1932E
Quick Inquiry
Key Features and Details
- Stock #N/A
- CategoryWork Platforms
- ClassLifting
- Hours—
Dealer Comments
JCB S1932E, JCB have used their experience in designing tough, hardworking equipment to ensure their electric scissors range are also built to higher standards. But as well as giving you tough, hardworking equipment, we also give you choice. Our access platforms are now available as hydraulic drive and electric drive. Whichever you choose, all come with higher levels of safety, ease of use, reliability and serviceability as standard. S1932E the compact electric scissor lift for operating in tight, restrictive spaces.
Specifications
| Body | Lifting |
|---|---|
| Category | Work Platforms |
| Make | JCB |
| Stock Number | N/A |
| Veh Type | New |
| Vin | 5815446 |
| Wheelbase | 1330 mm [52 in] |
|---|---|
| Tire Size | 305 x 115 mm |
| Hydraulic Tank Capacity | 14 L [3.7 gal] |
| Turning Radius Inside | 0.04 m [2in] |
| Turning Radius Outside | 1.49 m [4ft 11in] |
| Working Height | 7.71 m [25ft 4in] |
| Max Basket Height | 5.71 m [18ft 9in] |
| Max Drive Height | 5.71 m [18ft 9in] |
| Ground Clearance | 70 mm [2.8 in] |
|---|---|
| Overall Width | 820 mm [32 in] |
| Stowed Length | 1.78 m [5ft 10in] |
| Static Dimensions Basket Length | 1.64 m [5ft 5in] |
| Static Dimensions Basket Width | 0.75 m [2ft 6in] |
| Performance Dimensions Basket Length | 1.64 m [5ft 5in] |
| Performance Dimensions Basket Width | 0.75 m [2ft 6in] |
| Transport Height | 1850 mm [73 in] |
| Transport Length | 1.78 m [5ft 10in] |
| Extension Length Front | 0.9 m [2ft 11in] |
| Overall Length With Standard Basket | 1.78 m [5ft 10in] |
| Overall Width With Standard Basket | 0.82 m [2ft 8in] |
| Stowed Height Rails Lowered | 1.85 m [6ft 1in] |
| Stowed Height Rails Up | 2.12 m [6ft 11in] |
Please confirm all features with dealer.
