Description
The Aj48D Is The Latest Addition To Our Ever Growing Access Range. Our new articulated boom model is the most versatile access platform we've ever produced. With its market leading 48ft platform height and increased working envelope, no area is out of reach. The AJ48D also comes with JCB Livelink as standard, our industry-leading telematics solution.
Specifications
Manufacturer
JCB
Model
AJ48D
Year
2026
Category
Aerial Work Platforms
Subcategory
Access Platforms
Emissions
DieselT4
Machine Power Source
Diesel
Engine Manufacturer
Kohler
Engine Model
KDI 1903 TCR
Fuel
Diesel
Engine Output
36kW [48hp]
DC Power
110Ah
Fuel Tank Capacity
59L [16gal]
Brand
JCB
Carrier
Self Propelled
DC Voltage
12V
Tire Type
Solid
Basket Capacity - Max
250kg [551lb]
Basket Capacity - Max Reach
250kg [551lb]
Max Drive Speed 4WD
6.5km/h [4mph]
Min Drive Speed 4WD
1.1km/h [0.68mph]
Drive Speed - Lowered
6.5km/h [4mph]
Drive Speed - Elevated
1.1km/h [0.68mph]
Gradeability - 4WD
40%
Operating Weight
7885kg [17383lb]
Tire Size
33 x 12 - 20
Overall Width
2260mm [89in]
Stowed Length
7.35m [24ft 1in]
Static Dimensions Basket Length
0.85m [2ft 9in]
Wheelbase
2030mm [80in]
Stowed Height
2.23m [7ft 4in]
Ground Clearance
320mm [13in]
Static Dimensions Basket Width
1.83m [6ft]
Max Basket Height
14.7m [48ft 3in]
Working Height
16.7m [54ft 9in]
Basket Rotation Angle
160°
Up And Over Clearance
7.5m [24ft 7in]
Horizontal Outreach
8.3m [27ft 3in]
Slewing Angle
355°
Tailswing
0.12m [5in]
Performance Dimensions Basket Length
0.85m [2ft 9in]
Performance Dimensions Basket Width
1.83m [6ft]
Turning Radius - Inside
2.7m [8ft 10in]
Turning Radius - Outside
4.7m [15ft 5in]
